Anti-Vibration Collet Gland Assemblies

MAXIMATOR® anti-vibration collet gland assemblies are for use in applications where there could be extreme external mechanical vibrations or shock in tubing lines. These collet gland assemblies are interchangeable with standard medium pressure coned and threaded tube connections.

In normal coned and threaded tube connections, any external mechanical loading on the tubing lines, valves, or fittings would be concentrated on the first thread of the tube. This can cause failure of the tube at this thinner cross-section. The anti-vibration collet gland assembly grips the tubing behind the connection, supporting the tube at the full cross-section and straight area, moving the loading away from the threaded area.

Technical data

Body material316 L (1.4404)
Collar material316 L (1.4404)
Gland material316 L (1.4404)
Temperature-50˚ C to +350˚ C
Connections4MF, 6MF, 9MF, 12MF, 16MF
